Manufacturer Specifications:
- Tall sliding fence supports crown molding vertically up to 4-1/2 inches and easily slides out of the way for bevel cuts
- 0- to 50-degree miter ability for greater capacity in all cutting applications
- 11 positive miter stops allow for quick settings and improved accuracy
- Steel-on-steel detent plate and pin offers repeatable accuracy and worksite durability
- 0- to 48-degree bevel delivers increased capacity for out-of-square corners
- 33-pound weight, head lock-down pin, and built-in carrying handle for increased portability
- 15 amp motor, 5,000 rpm provides enough power for all cutting applications
- Works great with the DW723 miter saw stand
Specifications:
- Amps: 15 amps
- No-load speed: 5,000 rpm
- Blade diameter: 10 inches
- Arbor size: 5/8 inch
- Vertical capacity, baseboard against fence: 3-1/2 inches
- Vertical capacity, crown molding vertically nested: 4-1/2 inches
- Horizontal capacity, baseboard lying flat: 6 inches
- Horizontal capacity, crown molding lying flat: 5-1/4 inches
- 45-degree bevel cut capacity (dimensional lumber): 2-by-6 inches
- 90-degree crosscut capacity (dimensional lumber): 4-by-4 inches
- 90-degree crosscut capacity (max width): 2-by-6 inches, dimensional lumber
- 45-degree miter cut capacity (max height): 2-by-4 inches, dimensional lumber
- 45-degree miter cut capacity (max width): 2-by-4 inches, dimensional lumber
