2006 Heian NC-541PFMC CNC Router

Specifications

• 2006 Heian CNC Router
• Model NC-541PFMC
• 12 Position Tool Change
• 5 Routers
• 5 spindle Boring Block
• C axis on Spindle #1
• 5×10 Table
• Single 122″ x 64″ tables in a front to back configuration with an Extra Heavy Duty center supported bridge for high production, independent table operation.
• Spindle #1 8.8 kw spindle with C-axis & 12-position ride-along Tool Changer, spindle speed of 23,800 RPM, mounted on a pneumatically actuated cast iron slide for reduced vibration.
• Spindle #2 8.8 kw spindle, spindle speed of 23,800 RPM, mounted on a pneumatically actuated cast iron slide for reduced vibration.
• Spindle #3 8.8 kw spindle, spindle speed of 23,800 RPM, mounted on a pneumatically actuated cast iron slide for reduced vibration.
• Spindle #4 8.8 kw spindle, spindle speed of 23,800 RPM, mounted on a pneumatically actuated cast iron slide for reduced vibration.
• Spindle #5 8.8 kw spindle, spindle speed of 23,800 RPM, mounted on a pneumatically actuated cast iron slide for reduced vibration.
• #6 Piggy-back vertical borer with 5-spindles vertical in the X-axis
• Fanuc 210i – MB Controller.
• FANUC Brushless AC Servo motors with matching Servo amplifiers drive precision ground ball screws for axis motion, all axes ride on precision ground rectangular ways with tank type bearing; ballnut & way bearings are serviced by an automatic lubrication system.

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
