Features and Specifications:
- A 1.5 kW vacuum pump works with the membrane to ensure contour adhesion to even the biggest and most deeply profiled projects.
- State of the art inverter and PLC system control the table speed and movements.
- Integrated air tank system employs exhaust mufflers for a clean, quiet & safe workplace.
- A fully functional control panel is mounted on a swing arm for convenience. The controller can memorize up to 99 settings.
- Patented toggle table lift design eliminates expensive hydraulic repairs.
- Massive construction guarantees longevity and the ability to withstand the high pressures.
- The tables enter and exit on the same side of the machine saving valuable space. Load one while the other is being processed to increase production. Tables can be set to run
- Table-Internal Length – 50″ x 102.36″
- Table External Length – 53.15″ x 105.5″
- Working Height – 3.15″
- Working Table – Auto Two Table
- Motors of the Working Table – 0.4 kW x 2
- Installation of the Toggle – 4 Units
- Hydraulic Pump – 15 HP
- Hydraulic Cylinder – 80 mm Dia. x 2 Units
- Capacity of the Heater – 37 KwVacuum Pump – 1.5 Kw
- Weight of the Tables – 1.5 Ton
- Dimensions – 230.32″ x 88.58″ x 76.77″
- Weight of Machine – 9 Tons
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
