Features and Specifications:
- 22 hp
- laser light
- Very Rigid machine body with a welded steel frame with an integral cast & machine table, which is fitted with a sturdy cast column & saw unit
- Excellent precision work accuracy and durability
- Absolute straight line feeding to 13 ft.
- Precision caterpillar chain and double “VEE” extra long (47.2″) guide rails are made of special cast iron the chain connecting pins are made of high grade steel – heat treated & ground for
- high durability and low wear
- 8 hold-down rolls (6 rows)
- Swing Down Rear Table – to prevent damage to the table chain area
- Quick release cam & adjustment to the rip fence
- 3 sets of anti-kickback fingers. 2 top and 1 set in the table
- Precision Built Saw Arbor constructed of nickel chrome steel, large diameter, accurately ground, hardened and dynamically balanced
- Arbor runs in precision angular contact type ball bearings (eliminates any radial run-out and axial thrust) – V Belt driven from below
- VFD – Infinitely variable feed system with feed speeds of 30~130 fpm (10-40 mpm)
- Easy access controls mounted on a pendant – with easy adjustment to the controls
- Automatic Centralized lubrication system ensures permanent oil film between the chain and guide rail. When oil runs out the machine track stops running to avoid damage to track
- Complete with safety devices
- Soft start – Star Delta starter
- Solid steel round fence bar
- Telemecanique U/L magnetic starters to UL/CSA standards
- Usable chain length 47″
- Glue line Guarantee: 13 ft.
- Max. workpiece thickness 4.33″
- Min. workpiece length 8″
- Distance between saw adn column 18.1″
- Saw arbor diameter 1″
- Saw blade diameter 10-14″
- Saw arbor speed 4300 RPM
- Useable chain length 47″
- Glue line guarantee 13′ (+/-0.0098″ or 0.25mm)
- Feed speeds variable 30 to 130 FPM
- Arbor motor 20 HP
- Feed motor 2 HP
- Dust collection outlet 4″
- Table size 36.6″ x 64.6″
- Table height 31-7/8″
- Net weight 3190 lbs
- Shipping weight 3630 lbs
- Machine dimensions 78-3/4″ x 44″ x 64″
- Shipping dimensions 76-3/4″ x 53″ x 67″
- Electrics 230V /3 Phase /60 Hz
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
