Crown Mortar Mixer Model S6SR

Features and Specifications:

• Shaft R.P.M. Max: 38
• Wrap Thickness: 7 USG
• End Plate Thickness: 1/4″
• Drum Material: Steel
• Drum Width: 23-1/4″
• Drum Height: 27-1/2″
• Drum Length: 26 3/4″
• Capacity Bags: 2 to 2-1/2
• Capacity Cubic Feet: 6 cu ft
• Overall Height: 56″
• Overall Width: 49″
• Charging Height: 49″
• Length – Tow Pole Out: 93″
• Length – Tow Pole In: 65″
• Tires (Pneumatic): 5.50 x 12
• High Speed Bearings? Yes
• Gear reduction System? Yes
• 2 HP
• 110/220 Volts
• Phase 1
• 20.4/10.2 Amps

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

Please call for more information.

Note: PDF Copy of Operating Instruction and Maintenance Instruction & Part List Manual Available.
