Eaton 2000 Series; Standard Mount Motor

SOLD AS IS

Feature Code Description

• PRODUCT M MOTOR
• SERIES 02 2000 SERIES
• DISPLACEMENT 149 244.3 cm3/r [14.91 in3/r]
• MOUNTING TYPE AC STANDARD, 2 BOLT; 82.6 [3.25] PILOT DIA. 13.59 [.535] DIA. HOLES ON 106.4 [4.19] DIA. BOLT CIRCLE. SAE A
• OUTPUT SHAFT 02 31.75 [1.250] DIA. STRAIGHT SHAFT WITH .375-16UNC-2B THREAD IN END, 7.938 [.3125] SQ X 31.75 [1.250] STRAIGHT KEY
• PORTS AA .875-14 UNF-2B SAE O-RING PORTS – STAGGERED PORTS
• CASE FLOW OPTION 01 .4375-20 UNF-2B SAE O-RING PORT
• LOW PRESSURE RELIEF 0 NONE
• PRESSURE FLOW OPTION 00 NONE
• GEROLER OPTION 1 STANDARD
• SEAL OPTION 4 SEAL GUARD
• ACCESSORIES 00 NONE
• SPECIAL FEATURES (HARDWARE) 00 NONE
• SPECIAL FEATURES (ASSEMBLY) 00 NONE
• PAINT/PACKAGING AB PAINTED LOW GLOSS BLACK, INDIVIDUAL BOX
• CUSTOMER IDENTIFICATION AA NONE
• DESIGN CODE F SIXTH

Applications

• Skid Steer Attachments
• Swing Motor
• Brush Cutters & Mowers
• Harvesting Equipment
• Directional Boring any place pressure relief protection is optimal for system or motor performance and life
• Turf equipment
