SKU: 563-2

Feeler FTS-27 HA Series II Lathe

Out of Stock But wait, we have similar products

Features and Specifications:

  • This is a Feeler FTS-27 High Accuracy Series II Lathe.
  • This is the Feeler version of the Hardinge DSM-59 and the DV-59.
  • Serial No. 8FS126,
  • MFG. Date 06-1988,
  • Feeler is Made in Taiwan.
  • 220V/3PH/60HZ
  • Control voltage 110 Volt,
  • HP 2.0 / 1.0 Two Speed, Other motors 1/12 HP and 1/8 HP.
  • Hardinge Taper on Spindle nose.
  • Speeds: 230 – 3500 RPM (variable)
  • Spindle capacity with round 5C collets: 1-1/16″
  • Length of bed: 36″
  • Swing over bed: 9″
  • Travel of double tool cross slide: 3-3/4″
  • Travel of turret slide: 4″
  • Diameter of turret holes: 5/8″
  • Coolant sump capacity: 3 gallons
  • Estimated dimensions: 74″ x 35″ x 68″ high
  • Estimated weight: 1,000 lbs.



Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

Please call for more information.

Note: Original Copy of Operating Instruction and Maintenance Instruction & Part List Manual Available.

Weight 205.48 lbs
Dimensions 74 × 35 × 68 in
