Features and Specifications:
- Max Material Thickness 1-1/2″ Hole 3/8″ (Mild Steel)
- Angle Iron Capacity 4″ x 4″ x 1/2″
- Angle Iron Capacity @ 45° 3″ x 3″ x 5/16″
- Flat & Bar Shear 12″ x 5/8″ or 8″ x 3/4″
- Round Capacity 1-9/16″
- Square Capacity 1-9/16″
- Notcher 3-1/2″ x 1-5/8″ x 3/8″
- 10″ Deep Throat
- Motor 3 Kw
- Two hydraulic cylinders ironworker with two simultaneous work stations and five work stations.
- Punching (60 Tn power)
- Notching
- Shear of iron section L (110 Tn power)
- Shear of flatbar
- Cut of round and square bars
- Machines driven by two cylinders.
- 5 work stations, fitted with tools for L, shearing, round and square bars, rectangular notching and punching
- Quick change punch
- Flat bar shearing table with adjustable guides
- 2 simultaneous work stations
- Greater speed backed by a powerful hydraulic unit.
- Special equipment for approaching at reduced pressure and slow speed.
- Precision punching table with X & Y measuring stops.
- Precision notching table with X & Y measuring stops
- Ready for production pack comprising:One meter “touch & cut” length stop with fine adjusting.
- Lamp for enhanced vision of cutting zones.
- 10 sets of round punches and dies.
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
