Manufacturer Description:
- Length of oscillation:
- UP: 1/8’’ (3.2 mm)
- DOWN: 1/8’’ (3.2 mm)
- TOTAL: 1/4’’ (6.4 mm)
- Belt size: 6″ x 108″ (152 x 2743 mm)
- Belt speed: 3150 lin. fpm
- Front table size (l x w): 7 3/4” x 37″ (197 x 940 mm)
- Auxiliary table size (l x w): 11 3/4” x 19″ (299 x 483 mm)
- Dust outlet: 4” (102 mm)
- Base dimensions (l x w): 42” x 16 1/2” (1067 x 419 mm)
- Overall dimensions (l x w x h) 62″ x 20 1/2″ x 41″ (1575 x 521 x 1041 mm)
- Weight: 453 lbs (206 kg)
Features:
- Magnetic 2-step safety switch to prevent unintentional start-up is equipped with an extralarge easy access stop panel and a lock-out key to prevent unauthorized use.
- Tables can be adjusted up or down for full belt use.
- Front table can be inclined left or right.
- Innovative hinged dust hood accommodates oversized stock.
- Easy adjustment of abrasive belt tension with one knob only.
- Graphite backing reduces belt friction for longer belt life.
- Auxiliary table allows curved sanding.
- Heavy steel base ensures a solid stable.
- Oscillation feature.
