SKU: 539-38

General International 18″ heavy-duty wood cutting bandsaw

Out of Stock But wait, we have similar products

Features and Specifications:

Wheel size 18” (458 mm)
Wheel speed (2) 600 & 840 rpm
Blade speeds 2820 & 3936 lin. fpm (860 & 1200 lin. mpm)
Blade width 1/4” to 1 1/4 (6 to 32 mm)
Blade length 145 5/8” (3700 mm)
Table size 20″ x 24″ (510 x 610 mm)
Table tilt 0° to 45° (right)
Table height 37 3/8” (950 mm)
Maximum width of cut 17 5/8” (450 mm)
Maximum cutting (rip fence) 16” (405 mm)
Maximum depth of cut 12 3/8” (315 mm)
Dust outlets (2) 4” (102 mm)
Overall dimensions (l x w x h) 18 1/8” x 32 1/4” x 74 3/8″ (460 x 820 x 1890 mm)
Motor M1 3 HP, 220 V, 1 ph, 16 A
Weight 605 lbs (275 kg)
  • Safety foot brake simultaneously slows down the blade and disconnects electrical circuit for quick blade stoppage and emergency shut-off.
  • Heavy-duty one-piece frame, designed for added stability. Requires no further assembly. Dynamically balanced cast-iron
    wheels with replaceable rubber tires, mounted on heavyduty
    bearings.
  • Solid cast-iron table with heavy-duty one-piece trunnion and
    0° to 45° right tilting action for bevel cuts.
  • Two cutting speeds for excellent results in either hard or soft
    woods.
  • Convenient blade tension adjustment handwheel with tension scale.
  • Powerful, totally enclosed fan cooled (TEFC) industrial quality
    motor.
  • Magnetic safety switch with lock-out switch key to prevent
    unauthorized use.
  • Cast-iron miter gauge and dual miter slots in table for stable
    cross cuts on either side of the blade. Onboard storage
    mounts for miter gauge and rip fence.

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

Please call for more information.

Note: PDF Copy of Operating Instruction and Maintenance Instruction & Part List Manual Available.

Weight 124.74 lbs
Dimensions 18 × 32 × 75 in
Brand
Model
Serial
Voltage
HP
Phase
