Swing Over Bed 11″
Swing Over Carriage 9″
Swing Over Cross Slide 6″
Dist. Btwn Centers 18″
Compound Slide Travel 3″
Carriage Power Feed Range 5/16 – 7 IPM
Cross Slide Power Feed Range 3/16 – 4 IPM
Coolant Sump Capacity 3 Gal.
Spindle Capacity
With Round 5C Collets 1-1/16″
With Hexagon 5C Collets 7/8″
With Square 5C Collets 3/4″
With Step Chucks 6″
With Jaw Chucks 5″
With Expanding Collets 3″
Spindle Configuration 5C Hardinge
Hole Thru Spindle 1-1/4″
Infinitely Variable Spindle Speeds 100 – 3,000 RPM
Base Speed 1750 RPM
Power 5 HP
Torque 15 ft-lb.
Thread Range 4.0 – 250.0 TPI
Right-Left Hand Threads
4.0 – 10.0 TPI 250 RPM
10.1 – 24.0 TPI 1000 RPM
24.1 – 80.0 TPI 1500 RPM
80.1 – 250.0 TPI 2000 RPM
Multiple Start Threads Up To 4
Lead Screw Pitch 8 Pitch
Morse Taper Center MT No.2
Tailstock Spindle Diameter 1-3/8″
Tailstock Spindle Travel 3-3/4″
Approx. Dimensions 71.5″ x 31″ x 73″
Approx. Weight 2,250 lbs.
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
Note: Original Copy of Operating Instruction and Maintenance Instruction & Part List Manual Available.
