    SKU: 539-35

    Italpresse UT/6 Hotpress 51″x 138″

    Out of Stock But wait, we have similar products

    Italpresse UT/6 hotpress
    Italpresse UT/6 hotpress Italpresse UT/6 hotpress Italpresse UT/6 hotpress Italpresse UT/6 hotpress

    Features and Specifications:

    • Technical type Upstroking press
    • Side Loading Hotpress
    • Working table 3550 x 1300 mm
    • Daylight Opening 400 mm
    • Solid steel worktops
    • Rack guide for centered lifting
    • 6 Hydraulic Cylinders
    • Power 120 ton,
    • Volt. 400 V
    • Number of daylights 1
    • Pressure   3   kg/cm²
    • Total pressure t 120
    • Operating temperature max °C 120
    • Diameter cylinder mm 80
    • Heating power kW 18
    • Parallel guidance by toothed rack
    • Safety device
    • Pressing force
    • Electrohydraulic Heating platens : Thermo oil
    • Serial No: 96631197
    • Year: 1997
    • Net weight kgs. 3200

    Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

    Please call for more information.





    Weight 1451.49 lbs
    Dimensions 168 × 61 × 86 in
    Brand
    Model
    Voltage
    Phase
    Serial

    Out of stock?

    We have similar machines in used Woodworking Machines, Contact our used machienery experts for more details.

    By checking this box, I agree to receive SMS messages about reminders from Coast Machinery Group at the phone number provided above. The SMS frequency may vary. Data rates may apply. Text HELP for assistance. Reply STOP to opt out of receiving SMS messages Here is our Privacy policy
    We'll never share your information with anyone else.

    This unit is currently out of stock, but we have comparable machines in Used Presses. Here are few similar products in Used Presses
