These Compact, Cost-effective 4-side Moulders Enable Amazingly High Stability Plus Precision Moulding.
Manufacturer Specifications*:
- Working width (at a tool cutting circle of 140mm) 15-230mm(.59″-9.1″)
- Working height (at a tool cutting circle of 163mm) 10-150mm(36″-6″)
- Number of spindles, min-max 4-7
- Basic motor capacity per spindle 5.5 KW / 7.5HP
- Basic motor capacity of feed 4 KW / 5HP
- Spindle speed 6000 RPM
- Spindle diameter 40mm (50mm option)
- Tool cutting circle, first bottom spindle, min-max 125-160mm(4.9″-6.3″)
- Tool cutting circle, vertical spindles, left, min-max 112-200mm(4.4-7.9″)
- Tool cutting circle, vertical spindles, right, min-max 112-200mm(4.4-7.9″)
- Tool cutting circle, horizontal spindles, top, min-max 100-200mm(3.9-7.9″)
- Tool cutting circle, horizontal spindles, bottom, min-max 100-200mm(3.9-7.9″)
- Feed speed, infinitely variable by frequency driven motor 6-24 m/min(19.2-78 fpm)
- Feed roller diameter 140mm(5.5″)
- Feed roller width 50mm(2″)
- Pneumatic pressure for feed rollers, max 6 bar (87psi)
- Adjustment range for infeed table and edge-jointing fence 10mm(.39″)
- Adjustment range of vertical spindles (axial) 30mm(1.18″)
- Adjustment range of horizontal spindles (axial) 20mm(.78″)
- Length of the straightening table 2M(78.7″)
- Mechanical digital readouts for the pressure shoes & hold-down unit
- Full sound and safety enclosure
- Motorized vertical adjustment of feed
- Lateral pressure roller opposite first right spindle
- Chainless cardan feed system
- Diameter of dust hood for vertical spindle Ø125mm(5″)
- Diameter of dust hood for horizontal spindle Ø125mm(5″)
*Please call to confirm exact specifications
