Features and Specifications:
- Heavy-duty industrial motor
- Industrial-duty general-purpose mounted and wired magnetic starter
- Less than 5 PPM oil carry-over (blow-by) rating
- Pump RPM: 923
- 4-cylinder pump design
- 2-stage belt drive pump with solid cast iron cylinder
- Finned tube intercooler for maximum cooling and increased valve life
- Aluminum head for heat dissipation
- Extra-capacity oil reservoir for low oil temperatures
- Cast iron fly wheel for energy efficiency and durability
- Splash lubrication
- Low oil shutdown
- Heavy-duty aftercooler
- UL & CSA approval on all electrical components
- ASME-coded pressure relief valves and tanks
- Additional charge for liftgate shipping option
- Ship Weight 995.0 lbs
- Volts 230
- Max. PSI 175
- Motor Phase(s) 3
- Air Tank Size (gal.) 120
- CFM at 90 PSI 54
- CFM at Max. PSI 51
- Air Outlet Size (in.) 1
- Duty Cycle 100%
- Working Pressure (PSI) 145–175
- Stage 2
- Low Oil Shutdown Yes
- Lubrication System Splash
- HP 15
- Amps 42
- Drain System Automatic
- Pump Life (hrs.) 50,000+
- Pump Material Cast iron
- Dimensions L x W x H (in.) 78 x 28 x 55
Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.
Please call for more information.
