Weima ECO 1V 25HP 18 5KW Low Noise Waste Grinder

Features and Specifications:

• LOW HOUR UNIT!
• 25HP, 230 V, 3PH
• Vertical hopper w/ 32” x 39” top opening with taper side
• Hydraulic ram powered by 1.5 kWpump
• Hydraulic tank assembly
• Electrical control / panel box
• Hopper Opening: 23.6″ x 31.5″ (600 mm x 800 mm)
• Hopper Configuration: 4 sides straight
• Machine Opening: 23.6″ x 31.5″ (600 mm x 800 mm)
• Hopper Volume: 1.1 cubic yards (0.85 m³)
• Rotor: “V-Rotor”
• Rotor Diameter: 10″ (252 mm)
• Rotor Length: 23.6″ (600 mm)
• Rotor Speed: 80-120 RPM*
• Type of Cutter: 4 x indexable concave shape
• Size of Cutter: 1.57″ x 1.57″ (40 mm x 40 mm)
• # of Cutters: 14
• Extraction Requirements: 1,200 cfm, 6″ (160 mm) diameter
• Screen: 3/4″ (15/20mm)
• Output**: 400-600 lbs/hr (180-270 kg/hr)
• 16 ft Cable from Electrical Cabinet to Machine
• Soft Start with Star Delta Starter
• Anti-Vibration Foundation
• V-Rotor System
• 4-Times Indexable Concave Shaped Cutting Knives
• Reverse Counter
• Fast Hydraulic
• Gearbox Limit Switch
• Hardwood Package
• Serial No.: 500-8661
• Year Mfg: JULY 2007
• Dimensions: 64″ L x 52″ W x 65″ H
• Weight: 2,700 Lbs
• This is a used industrial grade wood grinding machine. The grinder uses a heavy rotary cutterhead and a hydraulic ram to grind wood, paper, plywood or plastic into manageable sizes. This reduces waste and waste removal costs.

Features, Specifications, Dimensions & Weight data is approximate and to the best of our knowledge.

Please call for more information.
